LM-10 Mixing Wet Granulator

Total Volume of Material Groove	10dm3
Working Capacity of Material Groove	2-6dm3
Feeding Quantity (Specific Gravity 0.5g/cm³)	1-3kg
Max Inside Diameter of Material Groove	300mm
Rotational Speed of Stirring Paddle	50-500r.p.m
Rotational Speed of Cutter	50-3000r.p.m

Inquire Now

Description

The LM-10 High-Efficiency Mixing Wet Granulator is a compact, versatile model designed for small-scale production in the pharmaceutical, food, and chemical industries. Equipped with advanced Siemens PLC control, a touch-screen interface, and variable-frequency speed regulation, it delivers precise control over the granulation process, ensuring uniform particle formation for small-batch applications.

Main Specification

Total Volume of Material Groove	10dm3	Total Height	1350mm
Working Capacity of Material Groove	2-6dm3	Lid Height	1300mm
Feeding Quantity (Specific Gravity 0.5g/cm³)	1-3kg	Machine Weight	260kg
Max Inside Diameter of Material Groove	300mm	Air Pressure	0.6-0.7Mpa
Rotational Speed of Stirring Paddle	50-500r.p.m	Cooling Water Pressure	0.1-0.2Mpa
Power of Stirring Motor	2.2Kw	Water Consumptian	1L/mni
Rotational Speed of Cutter	50-3000r.p.m	Air Conneltion	8mm
Power of Cutter Motor	0.75Kw	Cooling Water connetion	G1/G4/G8mm
Dimensions of Left Discharge (Model Standard)	1500*570mm	Power Cord Cross-Sectional Area	2.5mm²
Height of Discharge Outlet	700mm	Gross Weight	330kg
