Horizontal type packing with roll film or premade bag
Max speed to 100bags/min
Bag width from 50mm to 500mm with different models
| Bag Width Range | 55-200 mm | Packaging accuracy | ±1.5% |
| Bag Length Range | 100-280 mm | Air Consumption | 0.6 m³/min |
| Filing Range | 1 kg | Air pressure value | 0.6 Mpa |
| Max Speed | 30-50 (bags/min) | Power | 4kw,220V,380V,450V |
| Bag Width Range | 50-90 mm | Packaging accuracy | ±1.5% |
| Bag Length Range | 100-280 mm | Air Consumption | 0.6 m³/min |
| Filing Range | 200g | Air pressure value | 0.6 Mpa |
| Max Speed | 60-100 bags/min | Power | 4kw,220V,380V,450V |
| Bag Width Range | 80-250 mm | Packaging accuracy | ±1.5% |
| Bag Length Range | 100-280 mm | Air Consumption | 0.6 m³/min |
| Filing Range | 1kg | Air pressure value | 0.6 Mpa |
| Max Speed | 30-45 (bags/min) | Power | 4kw,220V,380V,450V |
| Bag Width Range | 50-115 mm | Packaging accuracy | ±1.5% |
| Bag Length Range | 100-280 mm | Air Consumption | 0.6 m³/min |
| Filing Range | 300g | Air pressure value | 0.6 Mpa |
| Max Speed | 60-100 (bags/min) | Power | 4kw,220V,380V,450V |
| Bag Width Range | 120-350 mm | Packaging accuracy | ±1.5% |
| Bag Length Range | 100-280 mm | Air Consumption | 0.6 m³/min |
| Filing Range | 1-3kg | Air pressure value | 0.6 Mpa |
| Max Speed | 15-35 (bags/min) | Power | 6kw,220V,380V,450V |
| Bag Width Range | 80-160 mm | Packaging accuracy | ±1.5% |
| Bag Length Range | 100-280 mm | Air Consumption | 0.6 m³/min |
| Filing Range | 1kg | Air pressure value | 0.6 Mpa |
| Max Speed | 50-70 (bags/min) | Power | 7kw,220V,380V,450V |
| Bag Width Range | 120-500 mm | Packaging accuracy | ±1.5% |
| Bag Length Range | 150-820 mm | Air Consumption | 0.6 m³/min |
| Filing Range | 1-5kg | Air pressure value | 0.6 Mpa |
| Max Speed | 3-15 bags/min | Power | 4kw, 220V, 380V, 450V |
Applicationsp:
Fill Energy Drink, etc. into pre-made pouches.Optional date printer, die-cut puches, etc.
Advantage: Horizontal single axis driven easy for maintain & clean, PLC+touch screen,easy to operate, no fillling and no sealing if the bag is not fully opened. Servo-driven single- directional pump filling to prevent liquid leakage.
